KX10DTP-WE

Two Way Wireless, 10m Dual Technology, Pet Immune Detector

  • Selectable EOL (End Of Line) resistors
  • Fully Two Way Wireless
  • Instant two way device control (ITDC)
  • 868MHz Transceiver FM technology
  • Blue wave technology
  • ABS plastics
  • Sealed optics
  • 10m Pet immune detection up to 20kg animal
Product Features
FeaturesDescription
Two way Wireless TechnologyEach wireless device on the Enforcer system, including movement detectors is a transmitter and a receiver. The wireless technology used on the Enforcer system holds a significant advantage over one way and some two way wireless products currently available on the market:
Instant two way Device Control (ITDC)The ITDC technology enables instant wake up and instant sleep of each device on the system, allowing continuous communication between the control panel and wireless devices while preserving battery power. This technology not only provides installers with total control of each device, but also gives users peace of mind that they have a reliable and secure wireless system.
- Ensuring that all wireless detection devices know when the system is armed and disarmed.
- Ensuring that they are awake as soon as the system is armed.
Signal Strength Indicator (SSI)One of the key advantages of implementing of the SSI technology is to allow the installer to view the wireless transmission signal strength on both the control panel and wireless devices in real time.
Sealed opticsProtects from possible infestation from insects, shields air movement in front of the pyro-electric sensor and protects against adverse reflections from inside the detector housing.
ABS plastics3mm polished finish, reduces electrostatic interference on the PIR sensor.
Blue wave technologyThis technology further enhances the detector’s immunity to infra-red noise in the environment. BWT comprises of 2 key components: 1). The new 3D optics system enables perfect focussing of the infra-red signal onto the pyro-electric sensor. This allows BWT to clearly identify the positive and negative signal edges. 2). Powerful software embedded into a microprocessor is used to process the received information from the pyro-electric sensor. The result of this combination is lower infra-red signal noise amplification and therefore better immunity.
Lens Coverage
KX10DTP-WE

KX10DTP-WE

Technical Specification
BATTERY
Battery lifeUp to 2 years

ENVIRONMENTAL (WIRELESS DEVICE)
Operating Temperature-10 to +40
Storage Temperature-20 to +50

DETECTION
Range10m
Zones30
Speed0.3- 3.0m/s
Angle85

WIRELESS DEVICE
Battery Type2 x 3.0V CR123A

TRANSMISSION
Transmission Frequency868MHz FM Transceiver Narrow Band
Transmission MethodFully Encrypted Rolling Code
Transmission Range300m Free Space

Information
COMPLIANCE (click image to download certificate)
CE
EN Europe
PACKING INFORMATION
Min Pack10
Warranty5 years
DesignedUK
